Intelligent Document Extraction

Key Information Extraction - Sync

Extract key information fields and table information from documents. Supported file formats: PDF, JPG, JPEG, PNG.

---

Request method:

• Request method: POST.

• Parameter transfer method: Body (form-data).

Request address:

https://localhost:7000/idp/intelligent-document-extraction

Request parameters:

Parameter name	Data type	Description	Required
file	File	Source document.	Yes
keys	array[string]	Key information fields.	No
tableHandles	array[string]	Table header fields.	No
pages	array[int]	Specify page number to extract.	No

When neither keys nor tableHandles exists, extract all key information in the file.

JSON content explanation

Return parameter	Data type	Description
code	String	Error code, "200" means success
message	String	Error message
data	Object	Return result
+details	Object	Key information extraction result
++Page-index	Object	Corresponding page number extraction result
+++key	String	Key information field extraction result, key:value
+++tables	Array	Key information table extraction result, tables:[ [table1], [table2] ]

JSON structure example:

{
    "code": "200",
    "msg": "success",
    "data": {
        "details": {
            "Page-1": {
                "Order Date": "xxx",
                "Order #": "xxx",
                "Quote#": "xxx",
                "Your estimated delivery date is": "xxx",
                "tables": null
            }
        }
    }
}

Key Information Extraction - Async

Extract key information fields and table information from documents asynchronously. Supported file formats: PDF, JPG, JPEG, PNG.

Upload and submit files

Upload the file you need to process and get fileId

Request method:

• Request method: POST.

• Parameter transfer method: Body (form-data).

Request address:

https://localhost:7000/idp/async/intelligent-document-extraction

Request parameters:

Parameter name	Data type	Description	Required
file	File	Source document.	Yes
keys	array[string]	Key information fields.	No
tableHandles	array[string]	Table header fields.	No
pages	array[int]	Specified page number extraction.	No

When both keys and tableHandles do not exist, extract all key information in the file.

JSON content explanation

Return parameter	Data type	Description
code	String	Error code, "200" means success
message	String	Error message
data	Object	Return result
+fileId	String	fileId

JSON structure example:

{
    "code": "200",
    "msg": "success",
    "data": {
        "fileId": "62132012acb86cf41ec9f6273f4026e8"
    }
}

Get processing results

Get the file processing results based on fileId.

If code or HTTP STATUS is 202, the file is being processed. Please call this interface later to get the file processing results.

Request method:

• Request method: POST.
• Parameter transfer method: Body (form-data).

Request address:

https://localhost:7000/idp/get-file-data-extract-result

Request parameters:

Parameter name	Data type	Description	Required or not
fileId	String	fileId	Yes

JSON content explanation

Return parameter	Data type	Description
code	String	Error code, "200" means success
message	String	Error message
data	Object	Return result
+details	Object	Key information extraction result
++Page-index	Object	Corresponding page number extraction result
+++key	String	Key information field extraction result, key:value
+++tables	Array	Key information table extraction results, tables:[ [table1], [table2] ]

JSON structure example:

{
    "code": "200",
    "msg": "success",
    "data": {
        "details": {
            "Page-1": {
                "Order Date": "xxx",
                "Order #": "xxx",
                "Quote#": "xxx",
                "Your estimated delivery date is": "xxx",
                "tables": null
            }
        }
    }
}

Error Code Reference

Return value:

Return parameter	Data type	Description
code	String	Error code.
msg	String	Error description.

Return example:

{
  "code": "08005",
  "msg": "Key information extraction failed."
}

Reference:

Error code	Description	Solution
'01001'	System internal exception.	Contact [email protected].
'01003'	File upload error.	Contact [email protected].
'03000'	Parameter verification exception.	Check file processing parameters, refer to API interface section.
'02321'	PDF file does not exist.	Contact [email protected].
'02002'	File size is 0.	Check whether the uploaded file is uploaded successfully.
'02004'	File processing failed.	Retry or contact [email protected].
'02006'	File return error.	Check whether the returned file is received normally or contact [email protected].
'01004'	File upload exception.	Contact [email protected].
'01005'	File cannot be empty.	Check whether the uploaded file is uploaded successfully.
'01203'	File cannot be found or cannot be opened.	Contact [email protected].
'02002'	File conversion in this format is not supported.	Contact [email protected].
'02207'	File opening failed: file type is not supported or encrypted.	Check whether the file has a protection password and whether the correct password parameter is passed in.
'04003'	File does not exist or cannot be opened.	Contact [email protected].
'07001'	Current function is not supported.	Contact [email protected].
'08100'	Invalid license.	Contact [email protected] to obtain the correct LicenseKey.
'08101'	The license has expired.	Contact [email protected] to obtain the correct LicenseKey.
'08102'	The license does not support the current platform.	Contact [email protected] to obtain the correct LicenseKey.
'08105'	The license does not have the permission for this function.	Contact [email protected] to obtain the correct LicenseKey.
'01006'	File parameter abnormality: Please set the correct file parameters.	Check whether the file parameters are correct.
'08002'	The executor does not exist or cannot be used	Check whether the executor is running normally
'08005'	Key information extraction failed.	Contact [email protected].

Status Code:

ComIDP uses HTTP status codes to return the results of your request. We mainly use two values ​​to inform you of the results of your request:

• 200 — A response with a status code of 200 indicates that the API call was successful.

• 413 — The API sends this status when your request size exceeds the limit.
